TTGO T5s V2.8 ESP32 2.7" EPaper Plus Module For Alexa I2S DAC MAX98357A MEMS Microphone ICS43434 Custom PCB customize

TTGO T5s V2.8 ESP32 2.7" EPaper Plus Module For Alexa I2S DAC MAX98357A MEMS Microphone ICS43434 Custom PCB customize

Regular price $32.21 USD
Regular price $72.21 USD Sale price $32.21 USD
Sale Sold out



TTGO T5s V2.8 ESP32 2.7" EPaper Plus Module For Alexa I2S DAC MAX98357A  MEMS Microphone ICS43434

Product Description

Lastest ESP32 Version: REV1

2.7″ePaper board consisting of ESP32-D0WDQ6, I2S DAC MAX98357A, and one pcs I2S MEMS microphone ICS43434

Single channel, Class-D amplifier embedded DAC, MAX98357 is connected to ESP32 through I2S bus.

MEMS microphone Invensense ICS-43434 is connected to ESP32 through I2S bus.

On-board USB-UART interface (CP2102) with several glue logic for direct binary uploading.

WIFI

Blth

4 MB Flash

3D ANTENNA

500mA Battery Management

LED indicator: There are 4 LEDs show the battery status in real time.

Power button: Click one time will start. Fast click 2 times will shut down.

2.7″ ePaper module 264*176 pixels,

TFCARD

Protection: Short protection. Over charging protection. Overflowing

button changed (IO37, IO38, IO39)



Pin Out Schematic





Dimensions

More product information,link to:

https://github.com/LilyGO/TTGO-T5S-Epaper

https://github.com/Xinyuan-LilyGO/LilyGo-T5-ink-series

Product Details



Screen Specifications




Part Number

Colors

Grey Level

Resolution

Display size (mm)

Outline Dimension (mm)

Full Refresh Time (s)

Partial Refresh Time (s)

Interface

2.7inch e-Paper

black, white

2

264x176

57.29 × 38.19

70.4 × 45.8

6

N/A

SPI

2.7inch e-Paper (B)

red, black, white

2

264x176

57.29 × 38.19

70.4 × 45.8

15

N/A

SPI






Shipped according to the kind of your choice


First kind With ePaper shipping list:

1 X TTGO T5s V2.8 2.7 inch Black White ePaper ESP32 Module

1 X Power Cable

1 X GROVE Line



Second kinds With ePaper shipping list:

1 X TTGO T5s V2.8 2.7 inch Red Black White ePaper ESP32 Module

1 X Power Cable

1 X GROVE Line

Third kinds Without ePaper shipping list:

1 X TTGO T5s V2.8 Without ePaper ESP32 Module

1 X Power Cable

1 X GROVE Line
















 Welcome Customize Order!
