LoRa-E5 (STM32WLE5JC) Module ARM Cortex-M4 and SX126x embedded supports LoRaWAN on EU868 &amp US915 Custom PCB customize

Note

LoRa E5 module has been favored by the community since its launch and the demand is far greater than our current batch supply. We have been working to stabilize the supply and will have enough stock in the coming weeks. The supply will be continuous and steady. If you have any questions regarding the module, tech support, large quantity purchase, and any further information on IIoT products and services, you are welcome to contact us at order[at][dot]cc

Note

We has recently released the LoRa-E5 Series based on LoRa-E5 module. Clickhereto meet new members of the LoRa-E5 family from the Grove module, mini Dev boards to Development Kit.



LoRa-E5 is a low-cost, ultra-low power, extremely compact, and high-performance LoRaWAN Module designed by Seeed Technology Co., Ltd. It contains ST system-level package chip STM32WLE5JC, and STM32WLE5 is the first SoC integrated with the combo of LoRa RF and MCU chip. This module is also embedded with ARM Cortex M4 ultra-low-power MCU and LoRa SX126X and therefore supports (G)FSK mode and LoRa.





The previous versions of the LoRaWAN module all require additional use of MCU (Microcontroller) to run the application code. Now, you can directly and immediately put the LoRa-E5 STM32WLE5JC Module into use to complete this process without the hustle of additional accessories. With the Stamp Hole form factor, LoRa-E5 enables you to integrate this module on your device’s mainboard conveniently. You don’t need to waste time and effort on designing your own device from scratch with the use of MCU and LoRa chip. Moreover, the module has already been certificated, so your completed device can be certified and approved by any agency cheaply and rapidly. Thanks to the innovative design, LoRa-E5 has a comparatively lower cost than other LoRaWAN modules. This will greatly save your budget in the whole process of product design.





LoRa-E5 LoRaWAN® module is highly suitable for long-distance, ultra-low-power applications such as smart agriculture, smart city, wireless meter reading, sensor networks, wireless communication, and other low-power wide-area IoT scenarios. If you want a module to design your own LoRaWAN sensor, to construct IoT nodes, or to support any wireless communication applications, LoRa-E5 is the premium choice that provides you with an optimal user experience.





If you are not quite familiar with LoRa and would like to learn more about it including what is LoRa? How does LoRa function? What are the pros and cons of LoRa? LoRa and LoRaWAN, LoRa network architecture, and applications of LoRa, etc.,  please check out this articleLoRapedia, which introduces LoRa and LoRaWAN in detail.
