DM556 Digital Stepper Motor Driver 2 phase 5.6A for 57 86 NEMA23 NEMA34 Stepper Motor Controller Replace TB6600

1. 24V-50V DC power supply, 8 level adjustable output current 1.0A-5.6A.

2. Bipolar constant current PWM drive output.

3. Optical isolation input signal, pulse response frequency up to 200kHz.

4. Strong anti-interference capability, achieve high precision positioning in complicated environment.

5. Low speed zero vibration, and low noise.

6. Fit for 42/57 stepper motor and widely used in automatic packaging machine, engraving machine and other automation equipments.







Specification:



Model: DM556

Application: 42/57 stepper motor







Input voltage: DC 20-50V

Output current: 1.0-5.6A, 8 level adjustable, 0.5A resolution

Drive method: Bipolar constant current PWM drive

Pulse response frequency: 200kHz(Max)

Insulation resistance: >500MOmega

Insulation strength: 500V/min

Dimensions: 118*75.5*34mm / 4.6*3.0*1.3in

Weight: Approx. 270g / 9.5oz
