DC24V 10A 250W Single Output Switching Power Supply for Raspberry Pi X450 DAC+AMP Expansion Board
DC24V 10A 250W Single Output Switching Power Supply for Raspberry Pi X450 DAC+AMP Expansion Board
Regular price
$47.49 USD
Regular price
$0.00 USD
Sale price
$47.49 USD
Unit price
per
Couldn't load pickup availability
Overview：
This is single output 24V 10A 250W Switching power supply, and it can provide upto 250W power output. It can be use to power Raspberry Pi X450 DAC+AMP Expansion Board,
Packing List:
1 x Switching power supply(EU/US Plug)
Features:
| Dimension | 215 x 115 x 50mm | |
| Working temperature | -10℃ ~ +50℃ | |
| Isolation resistance | I/P-O/P I/P-FG O/P-FG 500VDC/100MΩ | |
| Withstand voltage | I/P-O/P 1.5kV I/P-FG 1.5kV O/P-FG 0.5kV 1minute | |
| Setup, rise, hold up time | 200ms, 50ms, 16ms/230vac at full load | |
| Over voltage protection | 115%~150% shut down O/P voltage, re-power on the recovery | |
| OverLoad protection | 105% ~ 135% cut off the output, automatic recovery | |
| Impact current (Cold start current) | 25A/114VAC 50A/230VAC | |
| Input voltage range | 90~132VAC / 180~264VAC by Switch | |
| Adjustable range for DC voltage | ±10% | |
| Efficiency | 81.50% | |
| Load stability | ±1% | |
| Inlet wire stability | ±1% | |
| Wave and noise | 150mVp-p | |
| DC output voltage, current | 24V, 0~10A | |
| Model | S-250-24 | |
| Item | Description |
