Custom XH-M567 TPA3116D2 Dual-channel Stereo High Power Digital Audio Power Amplifier Board Audio Power Amplifier Board

Parameters: mono 80W dual-channel 40w+40w Power supply voltage: 24V-3A or more --8R/40W+40W

Product name: TPA3116D2 power level digital amplifier board
Chip type; TPA3116D2
Chip protection: over voltage and under voltage overheating DC detection of short circuit
Supply voltage :DC12^ 24V
Output power :80Wx2
Power efficiency :>90%
Channel number: Dual channel output
Product size :60*32* 14mm
Net weight: about 40g
