Custom VL53L1X laser ranging sensor module TOF time of flight ranging 4 meters

Not with an optical cover



Data download: https://pan.baidu.com/s/1Wb1w8lx5VqZ3MtyzZHZI9Q

Optical cover sheet description: dust-proof, water-proof, scratch-proof function, can help customers in the harsh environment of the application scenarios play a great role, is a can make up for the ST chip some defects of the protective cover sheet, to improve the module function



VL53L1X is an advanced time of flight (ToF) laser ranging sensor. It is a miniature ToF sensor, measuring range up to 4 m, fast measurement frequency up to 50 Hz, it uses a miniature reflow package, integrated SPAD receiver array, 940 nm stealth Class1 laser transmitter, Physical infrared filters and optical elements provide excellent ranging performance in a variety of ambient lighting conditions and provide a variety of window covering options. Unlike traditional infrared sensors, the VL53L1X uses STToF technology to measure range regardless of target color and reflectivity. The ROI size can also be programmed on the receiver array, allowing the sensor FoV to be reduced.

The main features

Fully integrated micromodule

Transmitter: 940 nm stealth laser (Class1)

SPAD (single photon Avalanche Diode) receiving array with integrated lens

Low power microcontrollers run digital firmware

Compatible with VL53L0X ranging sensor pins but incompatible with the program

Fast and accurate long-distance ranging

Distances measured up to 400 cm

Ranging frequencies up to 50 Hz

Typical Full field of view (FoV) : 27°

The programmable region of interest (ROI) size on the receiver array allows the sensor FoV to be reduced

A programmable ROI location on the receiver array that provides control of the host's multi-region operation

I2C interface (400 kHz)

Turn off and interrupt pins
