Custom Teensy 4.0 ARM Cortex-M7 Development Kit Development Board i.MX RT1060 Manufacturer

Name: Custom Teensy 4.0 ARM Cortex-M7 Development Kit Development Board i.MX RT1060 Manufacturer
Brand: Lonten Tech
Price: 100.00 USD
Availability: InStock

$100.00 USD

~~$0.00 USD~~ $100.00 USD

Sale Sold out

Quantity

Product Introduction
Teensy4.0 is the latest Teensy, which provides the fastest microcontroller and functions
Powerful peripherals, it has a 600MHz ARM Cortex-M7 processor and
NXP IMXRT1062 chip, which is the fastest microcontroller today. The size of Teensy4.0
And the shape is the same as Teensy3.2, and keeps compatible with most pin functions on Teensy3.2.
Allow
When running at 600MHz, Teensy4.0 consumes approximately 100mA of current. Teensy
4.0 provides support for dynamic frequency changes. Unlike traditional microcontrollers,
In the controller, changing the clock speed will cause the wrong baud rate and other problems, Teensy4.0
Hardware and Teensyduino's software support for the Arduino timing function is designed to dynamically change the speed
Serial baud rate, audio stream sampling rate, Arduino functions (such as delay0 and millis0)
And Teensyduino's extensions (such as ntervalTimer and elapsed Millis) in
The CPU can still work normally when the speed is changed.
Teensy4.0 also provides a power-off function. By connecting the button to on/off
Foot, you can completely disable the 3.3V power supply by pressing and holding the button for 5 seconds, and by briefly pressing the
Button to turn it back on. If a coin cell battery is connected to VBAT, when the power is turned off
The RTC of Teensy 4.0 will also continue to track the date and time. Teensy4.0 can also be overclocked,
Far more than 600MHz! ARM Cortex.-M7 brings a true real-time microcontroller platform
Has many powerful CPU functions.
The Cortex-M7 processor of Teensy4.0 includes a floating point unit (FPU), which supports
Supports 64-bit "double" and 32-bit "float".
