Custom STM32F769IDISCOVERY Discovery kit with STM32F769NI MCU Manufacturer

The STM32F7 discovery kit allows users to develop and share applications with the STM32F7 Series microcontrollers based on the ARM®Cortex®-M7 core.

The discovery kit enables a wide diversity of applications taking benefit from audio, multi- sensor support, graphics, security, video and high-speed connectivity features.

The Arduino™connectivity support provides unlimited expansion capabilities with a large choice of specialized add-on boards.

Key Features

• STM32F769NIH6 microcontroller featuring 2 Mbytes of Flash memory and 512+16+4 Kbytes of RAM, in BGA216 package

• On-board ST-LINK/V2-1 supporting USB reenumeration capability

• USB ST-LINK functions: virtual COM port, mass storage, debug port

• 4" capacitive touch LCD display with MIPI® DSI connector (on STM32F769I-DISCO only)

• SAI audio codec

• Two audio line jacks, one for input and one for output

• Stereo speaker outputs

• Four ST MEMS microphones on DFSDM inputs

• Two SPDIF RCA input and output connectors

• Two push-buttons (user and reset)

• 512-Mbit Quad-SPI Flash memory

• 128-Mbit SDRAM

• Connector for microSD card

• Wi-Fi or Ext-EEP daughterboard connector

• USB OTG HS with Micro-AB connector

• Ethernet connector compliant with IEEE-802.3-2002

• Five power supply options:

  • ST LINK/V2-1

  • USB HS connector

  • 5 V from RJ45 (Power Over Ethernet)

  • 5 V from Arduino™ or external connector

  • USB charger

• Power Over Ethernet based on IEEE 802.3af (Powered Device, 48 V to 5 V, 3 W)

• Power supply output for external applications: 3.3 V or 5 V

• Arduino™ Uno V3 connectors

• Comprehensive free software including a variety of examples, part of the STM32Cube package

• Supported by a wide choice of integrated development environments

•
