Custom South Korea INNO V7 Fiber optic Cleaver V7 FTTX FTTH Optical Fiber Cleaver Used in Fiber Fusion Splicer with 48000 Fiber Cleaver Manufacturer
Custom South Korea INNO V7 Fiber optic Cleaver V7 FTTX FTTH Optical Fiber Cleaver Used in Fiber Fusion Splicer with 48000 Fiber Cleaver Manufacturer
Couldn't load pickup availability
I assure you that the quality of our products to ensure that we give you the best service to ensure the fastest shipping, most secure way to deliver the goods to your hands! If you have any questions after receiving the product, or have quality problems, please do not panic, do feel to submit disputes, please contact our customer service, we will give you the most satisfactory answer! Happy shopping, thank you very much
Product Attributes
1. High precision cleaving for ribbon fiber cable as well as 250μm, 900μm,
2. 3.0mm and flat cable with universal holder.
3. Durable blade lifetime over 48,000 fiber cleaves.
Features:
Compatible with all VIEW series fusion splicer
Available for single and ribbon cleaving up to 12 fibers
Easy and simple 2 step operation
Automatic fiber shard collector (optional)
| Specifications | |
| Type | Single & ribbon fiber cable cleaver |
| Cladding Diameter | 125μm |
| Cleaved Length | Single fiber: 8~20mm / Ribbon fiber: 10mm |
| Applicable Fiber Cable | Single fiber: 250μm, 900μm, 3.0mm fiber cable and flat cable Ribbon fiber: 2 to 12 ribbon fiber cable |
| Typical Cleaved Angle | Less than 0.5 Degrees |
| Typical Blade Life Span | Total 48,000 fiber cleaves (1,000 fiber for 1 step * total 16 points * 3 heights) |
| Operation Steps | 2 Steps |
| Reclaim Function | Blade push back |
| Holder | Single: Universal holder Ribbon: Replaceable holder |
