Custom SHT30 temperature and humidity sensor probe module I2C communication air humidity detection sensor

Product parameters

Sensor model: SHT30

Supply voltage: 3.3V~5.0V

Measurement accuracy: temperature ±0.2℃ (0~65℃) Humidity ±2%RH (10~90%RH)

Measuring range: temperature -40~125℃ Humidity 0~100%RH

Response time: 8 seconds (TAu63%)

Power consumption: 4.8μ W (low repeatability at 2.4V, 1 time/second)

Long time drift: temperature < 0.03℃/ year humidity < 0.25%RH/ year

Output interface: standard IC2 protocol

Wiring length: 1 m

Wiring definition: Red -VCC black -GND Yellow -SCL green -SDA
