Custom Nexys A7-100T Xilinx FPGA RISC-V Development Board XUP Digilent Manufacturer

The Nexys 4 DDR is a drop-in replacement for a Digilent porous RAM-based Nexys development board. Equipped with Xilinx®Artix™-7 FPGA chip, Nexys 4 DDR is an out-of-the-box digital circuit development platform that enables users to implement many industrial applications in a classroom environment. Compared with earlier versions, the optimized Artix-7 FPGA chip can realize higher performance logic, and can provide more capacity, better performance and richer resources. Equipped with a large high-capacity FPGA chip (Xilinx part number XC7A100T-1CSG324C) and integrated USB, Ethernet and other ports, the Nexys 4 DDR development board enables a variety of designs from theoretical combinatorial circuits to powerful embedded processors . Several built-in peripherals: including an accelerometer, a temperature sensor, MEMS digital microphones, microphones and numerous I/O devices allow the Nexys 4 DDR to satisfy a wide range of design requirements. The most noteworthy improvement of the new generation of Nexys 4 DDR is the upgrade of the original 16 MiB CellularRAM to 128 MiB of DDR2 SDRAM memory. Digilent will provide a hardware description language (VHDL) reference module to encapsulate the complexity of the DDR2 controller and is backward compatible with CellularRAM's asynchronous SRAM interface, but with certain limitations.

Nexys 4 DDR is compatible with Xilinx's latest high-performance Vivado® Design Suite and ISE® Toolkit, which includes ChipScope™ and EDK. Xilinx offers a free version of the WebPACK™ toolkit to help users easily implement their designs at no additional cost.

product data:

Processor/IC:Xilinx Artix-7 FPGA XC7A100T-1CSG324C

Connector:

• UART/JTAG USB port

  Pmod supporting XADC signal

  audio connector

  Ethernet port

  USB host port

  microSD card connector

  12-bit VGA output

  4 Pmod ports

  Power outlet

  Programming Environment: Vivado Design Suite and ISE Toolkit

Features:

• Xilinx Artix-7 FPGA XC7A100T-1CSG324C

• 15,850 logic slices, each with 4 6-input LUTs and 8 flip-flops

  4,860Kbits of fast RAM

  6 clock management modules, each with a phase-locked loop (PLL)

  240 DSP slices

  Internal clock speed over 450MHz

  On-chip analog-to-digital converter (XADC)

  128 MiB DDR2

  Serial Flash

  Digilent USB-JTAG port for FPGA programming and communication

  microSD card connector

  Comes with sturdy plastic case and USB cable

  USB-UART bridge

  10/100 Ethernet PHY

  PWM audio output

  three-axis accelerator

  16 user switches

  16 user LEDs

  2 tri-color LEDs

  PDM microphone

  temperature sensor

  2 x 4-digit 7-segment displays

  USB HID host for mouse, keyboard and memory stick

  Pmod supporting XADC signal

  12-bit VGA output

  4 Pmod ports

Products include:

• Nexys 4 DDR Artix-7 FPGA
  micro usb cable...
