HD+VGA+ 2AV+YPBPR+Audio LCD Driver Controller Board Kit for Panel AT065TN14/AT070TN90/AT070TN92/AT070TN93/AT070TN94/AT090TN10
Tip: you need to provide LCD screen and LCD screen，According to different types of LCD, different procedures are used.
1. Product description:
This drive plate is ok
1 1 VGA signal input
2, 2. AV signal input
3 1 HDMI signal input, and the IC supports HD1.2
4 1 reverse signal input
5. Support wide voltage input, and can work between 9-21v, ()
6. Standard single interface 3.5 backlight terminal, input voltage is 8.5 v-10.5 V, (this voltage is for reference only, different screen voltage will be a little
In and out)
7. The drive plate adopts special circuit design, which can drive the LED backlight around 10V, and the maximum support of 500MA's current output,
8. Support, ttl-50p standard interface (see AT070TN92,), support ttl-40p standard definition interface (see ej070na-01j)
9, the standard 5 key presses the keypad interface, and supports the two-color LED indicator light display
10. Support TTL signal output,
Can support AT070TN92,
AT065TN14
AT080TN52
AT090TN12
AT090TN10
AT070TN90
AT070TN93
AT070TN94 et al, TTL LCD screen of universal 50PIN interface
11. With PCB800100, it can also support 4. 3, 5, 6, 7 inches, 40 pin universal screen, see AT043TN24V,1
The 12,40 pin-lvds definition interface can be directly driven by the firmware
EJ070NA01-1024 x600 resolution
EJ080NA04B - 1024 x768 resolution
EJ101NA - 02 - c - 1280 x800
G - 1280 x800 EJ101NA - 01
ZJ080NA - 01
Other models please check the LCD screen specification or consult my technology department
13. The maximum output display resolution of this drive panel is 1920X120 VGA and HDMI input (related to LCD)
14. Support reversing control, and display AV2, reverse voltage to support the voltage input within 50V (it is only possible to have voltage on this foot).
15. The positioning hole of the driving plate is four.
This controller board support Automatically Switch to AV2(Reversing View camera). Please connected ACC to 12V
