Custom Custom DC 9V 600mA Precision Switch Power Module Buck Module AC To DC Step Down Module Converter PCBA Manufacturer
Custom Custom DC 9V 600mA Precision Switch Power Module Buck Module AC To DC Step Down Module Converter PCBA Manufacturer
Regular price
$100.00 USD
Regular price
$0.00 USD
Sale price
$100.00 USD
Unit price
per
Couldn't load pickup availability
Features:
The product is easy to install and can be used directly on the motherboard.
The four corners have fixed mounting holes to prevent the product from being powered off due to movement and vibration. The
diameter of the fixing holes is 3.2mm.
Worldwide universal input voltage: AC 85-264V or DC 110-370V.
High efficiency, high power density, low output ripple, high output voltage accuracy.
High isolation between input and output.
Over current protection, short circuit protection and temperature protection.
Output built-in LC type filtering, no external filter circuit is required.
Parameters Introduced:
Input voltage :AC 85 To 264V / 110-370V DC
Output voltage: DC9V (± 0.2V)
Output current : 600mA
Power : 5.4W
Frequency Range: 47-63
Output voltage accuracy: 1%
Package Included:
3 x Precision Switch Power Supply Module
