Custom A8 Luxury Tone Board JRC5532+ALPS27 Type Potentiometer Preamplifier modules Manufacturer
Custom A8 Luxury Tone Board JRC5532+ALPS27 Type Potentiometer Preamplifier modules Manufacturer
Regular price
$44.46 USD
Regular price
$44.46 USD
Sale price
$44.46 USD
Unit price
per
Couldn't load pickup availability
Description:
All parts and components of this product are original authentic, unpretentious and pure in quality; using high-quality original
parts not only guarantees safety and quality, but also has a long service life, and more importantly, it is a strong guarantee
that the actual performance can reach the design goals.
Features:
1.JRC5532 is adopted.
2. The main circuit of electrolytic capacitor signal adopts famous brand, and the main filter capacitor adopts
ELNA680UF*2+1000UF*6, ensuring a strong and continuous power support.
3. The resistance adopts five-ring metal resistance, and the main circuit adopts the five-ring metal film resistance with the
precision ±1%, which ensures a good signal-to-noise ratio of the whole machine.
4. The left and right channel input coupling capacitors are coupled with WIMA2.2UF, making the high pitch clearer and the sound
sweeter! The combination of high and low sounds is more perfect!
5. PCB adopts 1.6mm thick double-sided plate, 2.0 Oz copper thickness and whole process of spray tin to ensure good pability of
current. First cl PCB quality.
6, the use of fully enclosed dustproof potentiometer, more stable performance, more durable than ordinary potentiometer!
7. The wiring layout of the whole circuit board is quite rigorous and reasonable. Stable and reliable operation, steady and solid
low frequency, excellent SIGNal-to-noise ratio, wide dynamic range; Clear details, excellent transient response, all kinds of
music can be played at ease, in the family playback environment has a very good performance.
8. The front stage is equipped with a direct switch, and the board is equipped with an op-Amp socket, which can be changed and
upgraded freely according to your own hobbies. It is flexible and convenient to use to meet different listening feelings.
Specification:
Supply voltage: AC 12V-18V.
Color: black
Material: ABS
PCB size: 270*60mm (width without potentiometer handle length)
Size: 56.5x56.5x67MM
Package included:
1 x Tone board
