Custom 3.2 inch TFT LCD Touch Screen Module Display Ultra HD 320X240 ILI9341 for 3.2'' 320240 240x320 240320 2560 diy Manufacturer

Custom 3.2 inch TFT LCD Touch Screen Module Display Ultra HD 320X240 ILI9341 for 3.2'' 320240 240x320 240320 2560 diy Manufacturer

Regular price $100.00 USD
Regular price $0.00 USD Sale price $100.00 USD
Sale Sold out

Product features:

-LCD control IC SSD1289 or ILI9341, touch panel controller XPT2046; default SSD1289
-Adopt industrial TFT LCD modules;
High-grade gold-plated double yellow-module pin, better electrical properties;
-Compatible with all hot Atom development boards, straight into the straight;
-Application is fully open source;
-Bottom-driven technical support LCD, a transaction, is a friend forever;


Hardware resources:

-3.2 inch, 240*320 resolution, TFT touch screen;
-Display driver IC SSD1289/ILI9341, touch screen driver for XPT2046;
16bit-display interface parallel interface, support for 6800 and 8080 bus interface supports STM32 FSMC bus interface, crowding the screen faster;
-Touch screen interface for the SPI interface, so that the line less, driving is simple;
-Onboard-a large current LDO voltage regulator, 5V and 3.3V power supply;
-Onboard PWM backlight control circuit to support IO control and PWM dimming control;
-Modules with SD cards, digital photo frames and other experiments can be done;
-Reserved SPI FLASH pad, you can extend the welded fonts chips;
-Supports landscape and portrait displays, support split the screen display;
-Support for 262,000-color RGB display and displayed good quality;
-Graphic display of the screen controller with internal 172800 byte data storage;
Punctuality Atom-interface compatible series of interface Development Board;
Patch-machine production, stable and reliable hardware;

Software resources:

-C51 monolithic integrated circuit testing source code;
-STM32 test source code;

Supporting other resources:

-Module design principle;
-LCD controller data manual;
-XPT2046 data sheet;
-Module schematic diagram;
-Module dimensions;
-LCD package;
MOD software-text;
-Picture taking mode software;
-C51 code wiring tutorial;
-STM32 code wiring tutorial;

Optional model:

-ILI9341 drive (recommended)

-SSD1289 drive


Product shipping list:
-QDtech 3.2 "TFT LCD touch screen LCD module x 1

-Give a touch pen x 1












 Welcome Customize Order!
