Custom 2.8 inch TFT LCD color touch screen module with PCB compatible atomic 34P LCD interface Manufacturer
Custom 2.8 inch TFT LCD color touch screen module with PCB compatible atomic 34P LCD interface Manufacturer
2.8 inch color screen, wide viewing angle, delicate display, 65K color rich
three hundred and twenty × 240 resolution, clear display effect
Support the plug and play of atomic full series development board, and no need to modify the code
Optional resistive touch panel (default) and capacitive touch panel (custom)
Support 8-bit / 16 bit parallel data bus switching, fast refresh
Military grade process standard, long-term stable work
Provide STM32 / C51 source code, Wiki information online update
Provide technical support for underlying driver
Display color: 16bit rgb65k color
SKU:MRB3512
Size: 2.8 inch
Screen type: TFT
Driver chip: nt35310
Resolution: 480 * 320 (pixel)
Module connection: 16bit parallel interface
Touch screen type: resistance angle worm touch open (black recognition), optional capacitance touch (5 points)
Operating temperature: - 10 ° ℃~60℃
Storage temperature: - 20 ℃ ~ 70 ℃
Working voltage: 3.3v/5v
Driver chip: ili9341
Working current: 135Ma (max)
Product weight (including package): 57g
