Custom 1PCSCJMCU-1334 DAC Module CJMCU-1334 UDA1334A I2S DAC Audio Stereo Decoder Module Board For Arduino 3.3V - 5V
Custom 1PCSCJMCU-1334 DAC Module CJMCU-1334 UDA1334A I2S DAC Audio Stereo Decoder Module Board For Arduino 3.3V - 5V
Regular price
$2.19 USD
Regular price
$4.19 USD
Sale price
$2.19 USD
Unit price
per
Couldn't load pickup availability
We are a manufacturer of electronic components, electronic modules for a large number of products.We are the factory!With more than 10 years of PCB development experience, the product quality is good, the price is excellent.A large number of wholesale sales of global buyers, welcome to purchase.
Feature: This fully-featured UDA1334A I2S Stereo DAC breakout is a perfect match for any I2S-output audio interface. 3.3V - 5V logic levels (a rarity), and can process multiple different formats by setting two pins to high or low. The DAC will process data immediately, and give you a clear, analog, stereo line level output. It's even cool with MCLK-less I2S interfaces such as the Raspberry Pi (which it's ideal for) - a built in PLL will generate the proper clock from the incoming signal. For inputs, you can use classic I2S (the default) or 16-bit, 20-bit or 24-bit left justified data. You can set it up to take an input system/master clock but we default-set it to just generate it for you, so you only need to connect Data In, Word Select (Left/Right Clock) and Bit Clock lines. If you want, there's a mute pin and a de-emphasis filter you can turn on.
