Custom 1PCS CC1101 Wireless Module SMA Antenna Wireless Transceiver Module For Arduino

We are a manufacturer of electronic components, electronic modules for a large number of products.We are the factory!With more than 10 years of PCB development experience, the product quality is good, the price is excellent.A large number of wholesale sales of global buyers, welcome to purchase.


Product Details:

Wireless Module
Condition: New
Operating frequency:(Module:387-464MHZ)
Working voltage :1.8-3.6V
Instantaneous maximum working current: <30ma>
Maximum transmit power: 10mW (+10dBm)
Features:
315/433/868/915MHZ ISM band
Support 2-FSK, GFSK and MSK modulation
Receiver sensitivity -110dBm at 1200 baud
Minimum operating speed 1.2kbps, the highest 500kbps
Separate 64-byte RX and TX data FIFO buffer
Built-in hardware CRC error detection ensures reliable data transmission
Support RSSI signal strength detection and carrier sense function
Low power consumption
Mailing Address (256) Operating frequency can be programmed via SPI
Programmable output power, for all the support frequencies up to +10 dBm
WOR feature can be set to standby, the proportion receiving state timer switch time to reduce power consumption
Fast frequency synthesizer with proper frequency hopping system
Color: show as pictures
PLS NOTE that due to lighting effects, monitor's brightness / contrast settings etc, there could be some slight differences in the color tone of the pictures and the actual item!

Package Included:
1 x Wireless Module ( including 2 extraposition antenna)
