Custom 1 set MEGA-2560 PCB Prototype Screw Terminal Terminal Block Shield Module Block Shield Board Kit Breakout Board Manufacturer

Custom 1 set MEGA-2560 PCB Prototype Screw Terminal Terminal Block Shield Module Block Shield Board Kit Breakout Board Manufacturer

Regular price $100.00 USD
Regular price $0.00 USD Sale price $100.00 USD
Sale Sold out


Descriptions:

Prototype Screw/Terminal Block Shield Board Kit For Arduino MEGA-2560 R3
The Kit include Prototype PCB, Terminal Blocks, Female Header Sockets
Unassembled, variety mount methods, you can make flexible use

PCB:

FR-4 fiber glass PCB, dual copper layers, size 120mm x 78mm
Pads grid / pitch 2.54mm / 0.1", hole diameter 0.8mm
Terminal block pitch 3.5mm / 0.138", hole diameter 1.2mm

Terminal Block:

Pitch 3.5mm / 0.138" mini terminal blocks, total 84 pins(3pole x24pcs, 2pole x6pcs )
Wire range 26~16AWG, strip length 5mm, screws M2 steel, pin header and cage brass

Female Header Socket:

Pitch 0.1"/2.54mm, pin length 15mm / 0.59"
Single row 10pin x1pcs, single row 8pin x 5pcs, dual row 18pin x1pcs

Package included:

1 x Double-side PCB Prototype Screw Terminal Block Shield Board Kit

 Welcome Customize Order!
