Altera Cyclone IV FPGA Entry Development Platform for beginners. Provide schematic, user manual in PDF, Verilog HDL demos with guideline, technical support during use it. 64Mbit SPI Flash; 128Mbit QSPI Flash, 1Gbit DDR2 (64M * 16bit), 16bit bus; EEPROM 24LC04, SD Card Slot Interface Connector 10/100/1000 Mbps Ethernet (RGMII) Connector, VGA video display, USB-to-UART, USB 2.0 Interface, Audio Port, 5 Keys, 6 LEDs, Digital Tube Real Time Clock, 5V DC Power Adaptor Three 40-pin connectors, expansion opportunities with ALINX Module, such as AD/DA data acquisition module, camera and LCD module Designed and manufactured by ALINX, that is XILINX Alliance Member in china.Providing customized services for enterprise
Key Features
FPGA: Intel/ Altera Cyclone IV EP4CE15F23C8 for AX515; EP4CE30F23C8 for AX530 Clocking: Fixed Oscillator with differential 50MHz output, used as the “system” clock for the FPGA Memory: Configuration chip SPI Flash: 64Mbit; QSPI Flash: 256Mbit; 1Gbit DDR2 for AX515 and 2Gbit DDR2 for AX530; IIC 30EEPROM 24LC04: 4Kbit (2*256*8bit); SD Card Slot Communication & Networking Gigabit Ethernet Connector, 10/100/1000 Mbps Ethernet (RGMII), Tri-Speed Ethernet PHY USB-to-UART Bridge Connector VGA Video Display interface USB 2.0 Interface Audio Port Configuration: Onboard JTAG header provided for use with AXSOC Brand Intel/ Altera download cables such as the Platform Cable USB II Expansion Connectors: 3-port 0.1 inch spacing standard 40-pin expansion headers Display: 5 Keys, 6 LEDs, Digital Tube Real Time Clock Power: 5V DC Power Adaptor Three-way Expansion Ports, Super Expansion Capability, Connect three different modules Simultaneously
