AX301C: ALTERA Cyclone IV EP4CE6 (FPGA Development Board + USB Downloader)
Intel Altera Cyclone IV Platform for beginners, affordable for students. Provide schematic, user manual in PDF, Verilog HDL demos with guideline, technical support during use it. FPGA: Intel Altera Cyclone IV fpga, 256/512Mbit SDRAM 16bit bus, 16MB SPI Flash, 4Kbit EEPROM 24LC04, SD Card Slot Interface Connector 18-pin CMOS cameral module interface, VGA video display, USB-to-UART, digital tube, buzzer, Real time clock, 4 keys and 4 user LEDs. Powered by Mini USB interface Two 40-pin connectors, expansion opportunities with ALINX Module, such as AD/DA data acquisition modules, camera and LCD modules Designed and manufactured by ALINX, that is XILINX Alliance Member in china. Providing customized services for enterprise
Product Description
It is an entry-level FPGA Development Board Kits, mainly for beginners, Intel ALTERA Cyclone IV FPGA. Expand two 40-pins standard connectors, directly connect with ALINX modules, such as ADDA module, 4.3-inch LCD screen, audio module, camera module, etc., providing more choices for engineers. Open Study version of Schematic/ PCB file/ Schematic file and PCB Library (in Altium Format). FPGA: Intel Altera Cyclone IV EP4CE6F17C8 Clocking: Fixed Oscillator with differential 50MHz output, used as the “system” clock for the FPGA Memory:2 56Mbit SDRAM (16M * 16bit), 16bit bus; SPI Flash: 16Mbit; IIC EEPROM 24LC04: 4Kbit (2*256*8bit); SD Card Slot Communication & Networking USB-to-UART Bridge Connector VGA Video Display interface 18-pin CMOS camera module interface Configuration: Onboard JTAG header provided for use with ALINX Brand Intel Altera download cables such as the Platform Cable USB Expansion Connectors: 2-port 0.1 inch spacing standard 40-pin expansion headers Display: 4 Keys, 4 User LEDs, Digital Tube Real Time Clock Buzzer Power: Mini USB interface.
